Customized Graphic 128*64 dot-martrix LCD module Reflective mode

Customized Graphic 128*64 dot-martrix LCD module Reflective mode

This is a unique customized COG module, of segment plus 128*64 dot-martrix. The LCD mode is STN Gray Positive Reflective mode without backlight, achieving the display effect of dark blue text on gray white background.

Size :
2.62"
Part No. :
FG-12864071-SAGA-N-G-A
Resolution :
128*64
Viewing Angle :
6:00
Interface :
MCU
Touch Screen :
/
Driver IC :
ST7567
Temperature :
0℃-50℃
Brightness :
50 cd/㎡
Module Outline(mm) :
66.50*43.80*2.00
A.A Size(mm) :
59.64*29.39
LCD mode :
STN(Gray)/Positive /Reflective

Inquiry now

categories

How can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Products Details

This typical customized COG module creates an unique display content, combing of a row of customer-specific icons above the display screen and a 128x64 dot matrix design below.

128*64 Graphic LCD Display

Display Type	STN Gray/positive /Reflective, COG module
Resolution	128*64
Model Size	66.543.82.00mm
V.A Size	63.9*36.5mm
Dot Size	0.41*0.41mm
Dot Gap	0.05*0.05mm
View Direction	6:00
Backlight	No Backlight
Driver IC	ST7567
Interface	Parallel 8080

Drawing:

128*64 Graphic LCD Display

Features:

Customized Icons: The designed customer-specific icons is placed above the screen, not only meeting personalized demands but also enhancing product recognition and aesthetics.
STN Gray Mode: It is STN Gray Positive Reflective mode, with a unique grey-white background and dark blue texts, improving information readability and visual appeal.
No Backlight: It requires no additional backlight, relying solely on ambient light for reflection, effectively saving energy. Under sunlight or bright light conditions, the display performance is particularly impressive, while also avoiding glare and heat issues associated with backlight.
Ultra-Thin Design: With 0.7/0.7mm glass, the whole LCD module achieves a thickness of just Max 2.0mm, contributing to a thin and lightweight design experience for terminal devices.
COG Module: By adopting the small size COG (Chip On Glass) driver IC, the COG module's size and weight are further reduced, enhancing integration and providing terminal products with a more compact design space and improved reliability.
Cost-Effectiveness: This customized 128*64 module selects the small-sized driver IC ST7567, combined with a no-backlight design, achieving minimal costs.

This customized 128*64 COG module is featured of personalized icon desgin, STN grey Positive Reflective mode without backlight, ultra-thin design and cost-effectiveness. It offers clients a unqiue customized display solution for the customer.

Customization Services:

The 128x64 dot matrix is one of the most popular resolutions among monochrome graphic modules, renowned for its stable process and cost-effectiveness.

We Shengfeng Technology, offer flexible customization services tailored to the customer's specific project needs.

Please contact us for detailed quotations and customized solutions. We are committed to providing high-quality, high-performance products, along with comprehensive after-sales service, to fulfill every one of your requirements. Don't hesitate to inquire now and embark on your journey towards customized display solutions!

Application:
