3.95 inch TFT LCD Display 480*480 40PINS RGB Interface

3.95 inch TFT Display

3.95 inch TFT LCD Display 480*480 40PINS RGB Interface

Part No.: FT-04009

TFT Type:  3.95 inch TFT LCD Display/ 3.95” IPS LCD TFT

Resolution:  480 x 480 dots

Viewing Direction:  All

Interface:  RGB

Driver IC: ST7701S

Luminance: 350 cd/m²

Touch Screen: with CTP touch

  • Item No :

    FT-04009

Product Details:

FT-04009 is a 3.95 inch TFT display of high resolution 480xRGBx480 with aspect ratio of 1:1 landscape mode. This standard 3.95” TFT model is featured with CTP touch screen, and being IPS LCD type. For mechanical detail, the model outline with touch screen is 85.60 x 85.60 mm, considered as a square TFT LCD. As a IPS, Normally Black, Transmissive product, this 3.95 inch TFT LCD Display can provides 800:1 high contrast ratio, and 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) viewing angle. This 3.5” TFT module is built-in with TFT LCD driver IC ST7701S-G5 supporting RGB Interface, and touch driver IC GSL1680 supports SPI type interface. The touch FPC is integrated into TFT FPC and final output 40PIN FPC connector.

Differ from the regular landscape or portrait mode, this 3.95 inch TFT LCD is 1:1 square TFT LCD. The special equal aspect brings a more intuitive and unique product appearance, and the square design is suitable for applications that require displaying square or nearly square content. For instance, in the design of board games, instrument panels, or certain specialized fields.



Product Drawing:

Custom Square TFT LCD



Product Specification:

No. Item SPECIFICATION
1 Part No. TF-04009
2 LCD Size 3.95 inch TFT LCD Display
3 Resolution (Pixels) 480(RGB)×480,
4 Display Mode IPS, Normally Black, Transmissive
5 Active Area 71.85 x 70.18mm
6 LENS Active Area 72.46 x 70.78mm
7 Module Dimension 85.60 x 85.60 x 3.50mm
8 Viewing Direction ALL View
9 Viewing Angle 85/85/85/85 (Typ.)(CR≥10)
10 Contrast 800:1 (Typ.)
11 Luminance 350 cd/㎡
12 Backlight 8 CHIP LED White,
13 Surface Treatment Anti-Glare
14 Temperature Range Storage Temp.: -30 ~ 80 °C   Operating Temp.: -20 ~ 70 °C
15 Touch Screen With CTP touch screen



Model FT-04009 is the standard touch display, 3.95 inch TFT LCD Display, 480x480 , RGB interface and CTP touch function. It belongs to IPS LCD and square LCD. If its current specifications cannot meet the customer's needs, we can provide customized services based on their specific requirements.

The customized service includes:

  • Customize backlight to adjust brightness and lifetime
  • redefine the interface type of TFT LCD or CTP touch type
  • Change FPC size, shape or position
  • Change to RTP touch or no touch
  • Re-design new cover glass
  • Add more functions of hardware and software



Application:

If the customer wants to more information about this special 3.95 inch square TFT LCD,Please feel free to contact us.
