1.54 inch TFT LCD 240*240 IPS LCD SPI Interface

FT-01516-B-N-A is a 1.54 inch TFT LCD display module, square mode of 240*240 resolution , About mechanical details, the active area size is 27.72×27.72mm and the module outline size is 31.52×33.72×1.95mm. This 1.54 inch IPS TFT display with full viewing direction with viewing angle of 80/80/80/80 (Typ.)(CR≥10). The TFT module is integrated with driver IC ST7789T3, of 4-wire SPI interface connected by 10-pin FPC.

FT-01516 is only 1.54 TFT display module without touch function. But it is optional to integrate RTP or CTP touch function.

Product Drawing：

Product Specification:

Products Features:

This 1.54-inch TFT display module is featured with a compact size, high resolution, square appearance, wide viewing angle, small size, and simple interface.

High Resolution: Despite its 1.54-inch screen size, it achieves excellent display quality with a resolution of 240x240 pixels.

Wide Viewing Angle: Equipped with an IPS display, it offers exceptional viewing angles (80/80/80/80), ensuring clarity from various angles.

High Brightness: While most 1.54-inch TFT displays have a standard brightness of 200-300 cd/m2, this model boasts a surface brightness of 400 cd/m2, delivering vibrant visuals.

Simple Interface: Leveraging the ST7789T3 driver and a 4-wire SPI serial interface, coupled with a 10-pin FPC connection, it significantly simplifies hardware design and wiring processes.

Unique Design: Featuring a 1:1 square aspect ratio and an ultra-thin narrow bezel design, it not only looks elegant but also saves valuable space, contributing to its fashionable appearance.

Customization Service:

Our company Shengfeng also accepts customization based on customer requirements, including interfaces, brightness, and touch screen solutions.

Applications:

The model#FT-01516-B-N-A, the 1.54-inch 240*240 TFT display is one of the popular display solutions of small size in the market.

Regarding specific applications, this 1.54-inch 240*240 TFT display can be utilized in medical devices, handheld detection instruments, smart wearable products, in-vehicle devices, and more.
