Size :
7.0"Part No. :
FT-07016-B-N-AResolution :
1024*600Viewing Angle :
FreeInterface :
RGBTouch Screen :
/Driver IC :
TBDTemperature :
-20℃-70℃Brightness :
1000 cd/㎡Module Outline(mm) :
164.89*100.00*5.56A.A Size(mm) :
154.21*85.92FT-07016-B-N-A is a 7 inch TFT display of high resolution 1024x600, SWVGA with aspect ratio of 17:10 (W : H) landscape type. As for mechanical detail, the model outline is 164.89 x 100.0mm and active area size of 154.21 x 85.92mm. As a IPS, Normally Black, Transmissive product, this 7” TFT can provides 800:1 contrast ratio, 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) viewing angle. Additionally, this 7 inch TFT module utilizes RGB as its signal inputting system, which connected by 50 pins FPC with power supply voltage of 3.3V.
For this 7 inch TFT display model, it is designed as high brightness TFT module, with surface brightness up to 1000 cd/m², which makes it is Sunlight Readable TFT display, ideal for automotive and other outdoor applications. Its high brightness ensures that the screen content remains clearly visible even under intense sunlight, enhancing user experience and operational convenience. Whether it's for automotive navigation, entertainment systems, or other outdoor devices, this high-brightness TFT display offers exceptional display performance to meet a wide range of usage needs.
Product Drawing:
Product Specification:
| No. | Item | SPECIFICATION |
| 1 | Part No. | TF-07016-B-N-A |
| 2 | LCD Size | 7 inch TFT LCD Display |
| 3 | Resolution (Pixels) | 1024(RGB)×600, WSVGA, |
| 4 | Display Mode | IPS, Normally Black, Transmissive |
| 5 | Active Area | 154.21 x 85.92mm |
| 6 | Bezel Opening | 155.85 x 89.38mm |
| 7 | Module Dimension | 164.89 x 100.0 x 5.50mm |
| 8 | Viewing Direction | ALL |
| 9 | Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| 10 | Contrast | 800:1 (Typ.) |
| 11 | Luminance | 1000 cd/㎡ |
| 12 | Backlight | 21 CHIP LED White， |
| 13 | Surface Treatment | Anti-Glare |
| 14 | Temperature Range | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 15 | Touch Screen | Without touch screen |
For 7 inch TFT display, we SF tech have 3 types with different resolution of 800×480, 1280×600, 1280×800. Customers could evaluate the specific application requirements and budget considerations before making a selection. Please feel free to contact us if you need any technical support.
Model FT-07016 is our SF tech’s existing standard part, 7.0 inch TFT LCD Display, high brightness and RGB interface, without touch function. If its current specifications cannot meet the customer's needs, we can provide customized services based on their specific requirements.
The customized service includes:
Adjust backlight brightness and lifetime
Adjust interface type conversion and position
Equip with RTP or CTP touchEquip cover glass only
Add more functions of hardware and software
Application:
