3.5 inch IPS TFT LCD 320*480 HVGA 700cd/m² Sunlight Readable SPI Interface Support CTP Touch Screen

The model #FT-03564-B-N-A, it is a 3.5 inch TFT LCD module features a resolution of 320(RGB)×480 (HVGA) with an aspect ratio of 2:3 (W:H) aspect ratio in portrait mode. The pixels are arranged in RGB vertical stripes, supporting 262K colors (6-bit). The active display area size is 48.96 × 73.44 mm (W×H), and display module outline dimension is 54.50 × 83.0 × 2.1 mm (W×H×D). With a surface brightness of 700 cd/m², the 3.5" TFT LCD Display ensures excellent sunlight readability.

The 3.5 inch IPS TFT LCD module is powered by ST7796U driver IC and supports a 4-wire SPI interface. The custom FPC includes two capacitive touch panel interfaces: one standalone 6-pin I2C interface on the left side and another integrated 20-pin FPC at the bottom side the LCD interface.

Product Drawing：

Product Specification:

Features:

✅ Portrait Design:  3.5 inch TFT LCD with 320×480 resolution and a 2:3 (W:H) aspect ratio, ideal for vertical display applications.

✅ IPS Wide Viewing Angles:  80/80/80/80 viewing angles for consistent performance from any perspective.

✅ Sunlight-Readable Display: 700 cd/m² high brightness ensures clear visibility in outdoor environments.

✅ Industrial-Grade Driver Solution: ST7796U driver IC with 4-wire SPI support simplifies circuit design and reduces development costs.

✅ Compact Structure:  The module thickness is 2.1mm only, optimized for space-constrained devices.

✅ Low Power, High Efficiency:  RGB vertical pixel arrangement and 6-bit color depth balance image quality and energy consumption.

✅ Dual Capacitive Touch Interfaces: Two touch panel interfaces (an independent 6-pin on the left / an integrated 20-pin at the bottom) for flexible touch integration options.

Customization Services

As a professional LCD manufacturer, we offer:

✅ FPC Length/Bending Direction Customization

✅ Backlight Brightness Adjustment (200–1000 cd/m² optional)

✅ Touch Panel Integration (Supports G+G/G+F Structures)

✅ Interface Protocol Expansion (MCU/RGB/LVDS, etc.)

Applications:

The Model #FT-035064, a 3.5 inch 320×480 TFT LCD module in portrait orientation (2:3 aspect ratio), delivers 262K-color display and 700 cd/m² brightness with IPS wide-view technology. It is an ideal solution for small-to-medium display needs in:

• Industrial Control: HMI interfaces, instrument panels
• Smart Wearables: Smart bands, health monitoring devices
• Medical Electronics: Portable diagnostic terminals, bedside monitors
• Outdoor Equipment: In-vehicle navigation, POS terminals, handheld devices.
