7.0 inch TFT LCD Display 1200*1920 Resolution MIPI interface High Brightness 750cd/m2 Custom Cover Glass

Features:

High Resolution:

The 7.0 inch TFT LCD Display boasts a high resolution of 1200RGB×1920, delivering a crystal-clear visual experience.

High Brightness:

With a module surface brightness of up to 750 cd/m², it maintains excellent visibility in bright light conditions (such as outdoors or in storefronts), making it an ideal choice for outdoor and high-end commercial equipment.

Full Viewing Angle:

The wide viewing angle of 80/80/80/80 (Typ.) ensures a consistent visual experience from any angle.

Efficient Interface:

The FT8206 driver IC integrated in this 7.0 inch TFT LCD Display supports the MIPI interface, offering advantages such as high transmission rates, low electromagnetic interference, and low power consumption.

With Cover Glass Design:

This 7.0 inch TFT LCD Display features a custom cover glass. The cover glass has a hardness rating of ≥6H, acting as a robust shield for the display screen. It effectively protects the display from scratches, abrasions, and impacts, extending its lifespan in harsh industrial environments or high-frequency public use scenarios.

Applications:

With its outstanding performance, including high resolution, high brightness, wide viewing angles, and optical bonding cover glass, this 7.0 inch TFT LCD Display module is a perfect solution for high-end applications across various industries.

• Industrial Control and HMI:  Industrial PLC touchscreens, human-machine interfaces, CNC machine display panels, and test and measurement equipment. The high brightness ensures visibility under strong factory lighting, while the robust cover glass withstands complex environments.

• High-End Commercial and Retail: High-end POS cash registers, self-service vending machines, smart parcel lockers, advertising kiosks, and queue management systems. The high resolution delivers exquisite product and advertising display effects.
• Medical Equipment:  Portable medical diagnostic devices, patient monitors, and handheld ultrasound machines. High resolution and accurate color representation are crucial for medical imaging displays.
• Outdoor and Portable Devices: Rugged handheld terminals, outdoor navigation devices, fishery detectors, and drone remote control image transmission displays. The high brightness meets viewing needs under direct sunlight outdoors.
• Smart Home and Security: High-end smart door locks/access control panels, smart central control screens, and security monitoring display terminals. The full viewing angle feature facilitates operation and viewing from different angles.
