Size :
7.0"Part No. :
FT-07008-B-N-AResolution :
800*1280Viewing Angle :
FreeInterface :
MIPITouch Screen :
/Driver IC :
ILI9881Temperature :
-20℃-70℃Brightness :
300 cd/㎡Module Outline(mm) :
99.65*160.90*2.44A.A Size(mm) :
94.20*150.72FT-07008-B-N-A is a portrait 7.0 inch TFT LCD display module, of high resolution 800*1280, of aspect ratio of 10:16 (W : H). About mechanical details, the active area size is 94.2(W)×150.72(H)mm and the module outline size is 99.65×160.9×2.44(H×V×D)mm. As AFFS LCD, Normally Black, Transmissive mode, this 7.0 inch TFT module features a high contrast ratio of 1000:1, and full viewing direction with viewing angle of 89/89/89/89 (Typ.)(CR≥10). The 7.0 inch TFT display is integrated with LCD driver IC ILI9881, supporting MIPI interface connected by a 31 pins FPC.
Product Drawing:
Product Specification:
| No. | Item | SPECIFICATION |
| 1 | Part No. | FT-07008-B-N-A |
| 2 | LCD Size | 7 inch TFT LCD Display |
| 3 | Resolution (Pixels) | 800(RGB)×1280 |
| 4 | Display Mode | FFS, Normally Black, Transmissive |
| 5 | Active Area | 94.2 x 150.72mm |
| 6 | Module Dimension | 99.65 x 106.9 x 2.44mm |
| 7 | Viewing Direction | ALL |
| 8 | Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| 9 | Contrast | 1000:1 (Typ.) |
| 10 | Luminance | 300 cd/㎡ |
| 11 | Backlight | 27 CHIP LED White， |
| 12 | Surface Treatment | Anti-Glare |
| 13 | Temperature Range | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 14 | Touch Screen | Without touch |
Features:
Portrait type structure: Specifically designed for Portrait mode applications, providing a more intuitive and ergonomic viewing experience.
High resolution: The high resolution 800*1280, ensures clear and detailed images, revealing more intricate details.
Wide viewing angle: Utilizing FFS wide viewing angle technology, achieving a 178° wide viewing angle with no color difference.
High contrast ratio: With a high contrast ratio of 1000:1, images appear sharper and colors are more vibrant.
MIPI interface: Supports the 4L MIPI interface, capable of providing stable and high-speed data transmission.
Ultra-thin thickness: The module has a total thickness of 2.44MM, and its ultra-thin design facilitates integration into various compact devices.
Customization Service：
The model# FT-07008-B-N-A, a 7.0 inch 800*1280 IPS MIPI Interface Portrait TFT LCD, is one of the standard 7.0 inch modules we can offer. Our company Shengfeng also provides 7.0 inch TFT modules with resolutions of 1024*600 and 800*480.
In addition to standard TFT modules, Shengfeng is capable of providing customization solutions, to tailor the module structure, dimension, backlight structure and brightness, interface type, FPC size and position, add or modify touch screen, or choose different TFT LCD panels and driver ICs according to customer specific requirements.
Applications:
Due to the features of high resolution, wide viewing angle, ultra-thin thickness, this 7.0 inch TFT # FT-07008 is recommended to be used in areas that require high-quality display effects, such as:
