Size :
7.0"Part No. :
FT-07004-B-N-AResolution :
800*480Viewing Angle :
12:00Interface :
RGBTouch Screen :
/Driver IC :
TBDTemperature :
-20℃-70℃Brightness :
250 cd/㎡Module Outline(mm) :
164.90*100.00*5.70A.A Size(mm) :
154.08*85.92FT-07004-B-N-A is a classic 7.0 inch TFT LCD display module, of resolution 800*480, WVGA. It is landscape mode, offering an aspect ratio of 5:3 (W : H). In terms of mechanical details, this 7.0 inch TFT module features a standard active area size of 154.08(W)×85.92(H) mm and the module outline size of 164.9(H)×100(V) ×5.7(D) mm, exclusive of an 85.14mm FPC cable length. This mechanical specifications ensures it full seamless compatibility with the vast majority of 7.0 inch TFT models in the market.
The other feature of this 7.0 inch TFT display is main viewing direction 12:00 o’clock, wide temperature and parallel RGB interface, connected via a 50 pins FPC.
Product Drawing:
Product Specification:
| No. | Item | SPECIFICATION |
| 1 | Part No. | FT-07004-B-N-A |
| 2 | LCD Size | 7 inch TFT LCD Display |
| 3 | Resolution (Pixels) | 800(RGB)×480, WVGA |
| 4 | Display Mode | TN, Normally White, Transmissive |
| 5 | Active Area | 154.08 x 85.92mm |
| 6 | Bezel Opening | 156.9 x 89.3mm |
| 7 | Module Dimension | 164.9 x 100.0 x 5.7mm |
| 8 | Viewing Direction | 12:00 |
| 9 | Viewing Angle | 70/70/70/50 (Typ.)(CR≥10) |
| 10 | Contrast | 500:1 (Typ.) |
| 11 | Luminance | 250 cd/㎡ |
| 12 | Backlight | 21 CHIP LED White， |
| 13 | Surface Treatment | Anti-Glare |
| 14 | Temperature Range | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 15 | Touch Screen | Without touch |
Features:
Model FT-07004-B-N-A, this 7-inch 800*480 TFT module is one of the popular and common size and resolution combinations in the market:
Compatible Mechanical Specs: The mechanical design of this 7 inch TFT is consistent with mainstream specifications on the market, ensuring full compatibility.
High Cost-Performance Ratio: Although the 800*480 resolution is not the highest, it is one of the most popular resolutions for 7-inch screens, offering a high cost-performance ratio.
Customization Service：
Shengfeng offers 3 types of 7.0 inch TFT LCD modules with different resolutions, including 800×480, 1280×600, and 1280×800. These modules support both landscape and portrait modes, providing customers with more options to choose from. At the same time, Shengfeng provides flexible customization services to meet the specific needs of different customers. These services include:
• Adjusting Backlight Brightness and Lifespan: Adjusting the backlight brightness of the module according to customer requirements to achieve the best visual effect and optimize its lifespan.
• Interface Type Conversion and Position Adjustment: Providing interface type conversion services to accommodate the connection needs of different devices, and adjusting the interface position as required.
• Equipping with RTP or CTP Touch Screens: Offering customers the option of resistive (RTP) or capacitive (CTP) touch screens to meet the requirements of touch operation.
• Cover Glass Only Option: For customers who do not require touch functionality, providing modules equipped with protective glass only to safeguard the screen from scratches and damage.
• Adding Additional Hardware and Software Functions: Enhancing the module's application range and performance by adding extra hardware and software functions based on customer demands.
Applications:
The 7 inch 800*480 TFT LCD diaplay has received widespread popularity in the market due to its moderate size and high resolution. It is widely applied in various fields such as vehicle-mounted navigation, industrial control, medical equipment, smart home, and more.
