2.2 inch 180*454 TFT Display IPS LCD In-cell Touch Customized Cover Glass

Model #FT-02203-B-L-A, this 2.2 inch TFT LCD display features a specific resolution of 180(RGB)×454, portrait mode of aspect ratio of 3:8 (W:H). Its active area size measures 20.79×52.44 mm, utilizing 0.25+0.25 mm glass substrate paired with an ultra-thin backlight, resulting a ultra-thin display module thickness just 1.66mm. It is a 2.2 inch IPS TFT display with exceptional display quality, offering a viewing angle of 80/80/80/80° (Typ.) (CR≥10) and a high contrast ratio of 1200:1.

Besides, the 2.2 inch TFT display comes with In-Cell Touch technology, utilizing the SPD2010 driver IC. It supports an SPI interface for LCD display and I2C interface for the touchscreen. And the display and touch interfaces are integrated into a single 31PIN-FPC connector. This 2.2 inch LCD touch display is optically bonded to a customized cover glass, of thickness of 1.1mm and surface hardness of ≥6H.

Product Drawing：

Product Specification:

Product Feature:

• Unique Specifications: The 2.2 inch TFT LCD display provides a delicate visual experience with its unique resolution of 180*454.
• Screen Structure:  The aspect ratio of 3:8 (W:H) and vertical narrow-bar structure are ideal for special application scenarios, offering users a more intuitive and convenient visual experience.
• Ultra-thin Structure:  With a display module thickness of just 1.66mm, this 2.2 inch LCD module meets the requirements of various ultra-thin devices.
• IPS TFT Technology:  This 2.2 inch IPS TFT LCD delivers exceptional display quality, with a viewing angle of 80/80/80/80° and a high contrast ratio of 1200:1.
• In-Cell Touch: The integrated In-cell Touch function enhances touch sensitivity and accuracy, while also simplifying the screen structure for more convenient operation.
• Integrated FPC:  The display and touch interfaces are integrated into a single FPC, simplifying the connection process and improving reliability.
• Glass Cover:  The customized cover glass not only creates a unique and personalized appearance but also effectively resists scratches and wear, extending the display's lifespan.
• Optical Bonding:  OCA optical bonding between the 2.2 inch TFT LCD display and the enlarged customized glass cover, to reduce reflection and enhance visual effects.

Applications:

Model #FT-02203, the 2.2 inch touch display module is suitable for small electronic devices such as smartwatches, portable medical equipment, and automotive displays. With its unique high-definition display, ultra-thin design, wide viewing angle,high contrast, and in-cell touch function, it adds highlights to products and enhances user experience.

Guangdong Shengfeng Technology Co., Ltd., as a professional LCD display manufacturer, has rich experience in producing monochrome passive LCD, color TFT LCD, touch screen, CG glass cover,  and display intelligent control solutions. We welcome inquiries for customized needs, and our R&D and design team will provide you with comprehensive technical support and solution suggestions to ensure that each screen perfectly integrates into your products.
