Automotive Display Module bar-type 3.9 inch 480*128 TFT LCD Customized Cover Lens 600cd/m2

• Bar-shaped Design: The 3.9 inch TFT LCD Display with 480*128 resolution and >3:1 aspect ratio, in landscape strip form, is ideally suited for applications such as vehicle instrument panels and industrial control panels.
• Ultra-wide Temperature Range: Designed for complex industrial and outdoor environments, it operates reliably in extreme hot and cold conditions, from -30°C to 85°C, ensuring stable performance in harsh industrial settings and extreme weather.
• High Brightness: With a surface brightness of 600 cd/m² (LCM+LENS), the display remains clearly visible under strong outdoor sunlight, making it suitable for challenging lighting conditions.
• High-performance Interface: Powered by the NV3041A driver IC and a 30PIN MIPI interface, it delivers stable driving, efficient data transmission, low failure rates, and long mean time between failures (MTBF), ideal for continuous operation.
• Custom Glass Cover: The uniquely shaped glass cover can be customized to match specific device requirements, balancing practicality and aesthetics.
• Optical Bonding: The display module and glass cover are bonded using OCA optical adhesive technology. This eliminates air gaps, reduces reflections, enhances display clarity and image quality, and effectively prevents dust and moisture from entering the module, significantly extending its service life..

Applications:

This bar-type 3.9 inch TFT LCD display module, featuring optical bonding and custom shaped glass covers, combines a 480*128 resolution with IPS full-view technology. Its 600 cd/m² high brightness ensures clear visibility outdoors, while the -30~85°C ultra-wide temperature range guarantees reliable operation. Paired with the NV3041A driver IC and 30PIN MIPI interface for stability and efficiency, and the strip design tailored for vehicle instruments and industrial control panels, it is the preferred core component for industrial, automotive, and outdoor display devices.
