2.0 inch TFT LCD, 240*296, IPS TFT, High Brightness 600 cd/m², Round corners

FT-02024-B-N-A is a unique 2.0 inch TFT LCD display, of resolution 240xRGBx296, portrait mode. For mechanical detail, this 2.0 inch TFT LCD Display is having active area size of 32.40 x 39.52mm and the module outline dimension of 34.04 x 43.37 x 1.60mm, with touch screen. The optical mode of the 2.0” TFT LCD is HADS, Normally Black, with all view direction as 85/85/85/85 (L/R/U/D), and high contrast up to 1200:1. This 2.0 inch TFT LCD display is built-in with driver IC ST7789T3 supporting MCU interface connected by 28pin back-side FPC.

Product Specification:

Product Drawing：

Product Features:

The uniqueness of this 2.0 inch TFT module is its distinctive shape design and ultra-thin profile.

• Distinctive shape : This 2.0 inch TFT module is not conventional rectangular appearance, adopting a design with rounded corners at all four sides. This design not only imparts a significant visual aesthetic and modernity to the product but also presents a more rounded and harmonious overall look, mitigating any potential visual and tactile discomfort caused by sharp edges.

• Ultra-thin thickness: The other highlight of this 2.0 inch TFT LCD is its ultra-thin design, with a total thickness of merely 1.60mm. This ultra-thin design not only makes the 2.0 inch TFT module itself lighter and easier to integrate into various devices but also offers users a more compact and space-saving visual experience. It further brings about other advantages. For instance, it contributes to reducing the overall weight of the product, enhancing the user experience. Simultaneously, it also improves the heat dissipation performance of the product, as a thinner body allows heat to dissipate more rapidly, mitigating the risk of performance degradation or damage due to overheating.

Applications:

The model#FT-02024-B-N-A, 2.0 inch TFT LCD module this 2.0-inch TFT module, with its unique shape design and ultra-thin characteristics, has secured a distinctive position in the display market. It perfectly caters to modern consumers' demands for unique appearances, lightness, and space-saving properties, making it highly suitable for handheld electronic products markets that prioritize unique, fashionable designs, thinness, and portability, such as smartwatches.
